IP-COM PoE Swicth รุ่น G5328P-24-410W
รายละเอียดโดยย่อ
G5328P-24-410W
IP-COM PoE Swicth รุ่น G5328P-24-410W
- G5328P-24-410W เป็นสวิตช์ PoE ที่มีการจัดการ IP-COM Layer-3 เพื่อตอบสนองความต้องการในการเข้าถึงที่มีประสิทธิภาพสูงสวิตช์นี้มีพอร์ตอีเธอร์เน็ต Base-T 24 10/100/1000 Mbps และพอร์ต Base-X SFP 1000 Mbps แยกต่างหาก 4 พอร์ตและกำลังไฟ PoE สูงถึง 370 W. พร้อมด้วยฮาร์ดแวร์ที่เป็นนวัตกรรมใหม่
ข้อมูลทางเทคนิค
| Standards | IEEE802.3,IEEE802.3u,IEEE802.3ab,IEEE802.3ad,IEEE802.3z,IEEE802.3x,IEEE802.1p,IEEE802.1q,IEEE802.1w,IEEE802.1d,IEEE802.1s,IEEE802.3af/at |
| LED indicators | One Link/Act or PoE LED indicator for each port One Link/One Link/Act mode converting LED indicator for each device One PoE mode converting LED indicator for each device One PoE Max LED indicator for each device One Power LED indicator for each device One SYS LED indicator for each device |
| Interfaces | 24 x 10/100/1000 Base-T Ethernet ports (Data/Power) 4 x 1000 Base-X SFP ports (Data) |
| Lightning protection | Port: 6kV Power: 6kV |
| Forwarding mode | Store-and-forward |
| Switching capability | 56Gbps |
| Packet forwarding rate | 41.7Mpps |
| Buffer | 12Mbit |
| MAC address table | 16K |
| PoE power supply | Ports 1 to 24 support IEEE 802.3af/at standard PoE power supply1 2 4 5 +, and 3 6 7 8 - |
| Whole switch consumption | Whole switch consumption: <410W Maximum PoE output power: 370 W |
| Input voltage | AC：100-240V～ 50/60Hz |
| Dimensions | 440 mm x 284 mm x 44 mm(L*W*H) |
| Operating environment | Operating temperature: 0°C - 45℃ Storage temperature: -40°C - 70°C Operating humidity: (10% - 90%)RH, non-condensing Storage humidity: (5% - 90%)RH, non-condensing |
| Certificates | CCC、FCC、CE、RoHS |
| PoE power supply management | Supports port PoE configuration and power supply with priority Supports PoE over-temperature protection Supports PoE scheduled management Supports intelligent and graphical management and PoE-powered device detection (port status, power assignment and PoE-powered device status) |
| Security features | Supports ARP receiving limit Supports unknown MAC address discard Supports DoS attack defense Supports 802.1x security authentication Supports Radius authentication |
| VLAN | Supports IEEE 802.1Q VLAN Supports VLAN Layer-3 interfaces Supports three port modes: Access, Trunk and Hybrid |
| DHCP | Supports DHCP Relay Supports DHCP Snooping Supports Option 82 policy configuration |
| L3 Routing | Supports VLAN-based routing Supports IPv4 static routing Supports static ARP |
| Port aggregation | Supports static aggregation Supports LACP dynamic aggregation |
| Spanning tree | Supports IEEE 802.1d STP (Spanning Tree Protocol) Supports IEEE 802.1w RSTP (Rapid Spanning Tree Protocol) Supports IEEE 802.1s MSTP (Multiple Spanning Tree Protocol) Supports edge port Supports BPDU statistics |
| Multicast | Supports IGMP Snooping V1/V2/V3 Supports port fast leave |
| Port Mirroring | Supports N: 1 port mirroring |
| QoS | Supports SP (Strict Priority) Supports SWRR (Simple Weighted Round Robin) Support WRR (Weighted Round Robin) Supports 802.1p port trust mode Supports DSCP port trust mode Supports a maximum of 8 queue service quality mapping |
| ACL | Supports MAC ACL Supports IP ACL |
| Loading and upgrade | Supports FTP/TFTP/HTTP upgrade Supports configuration import and export |
